- Size: 110x77x38mm
- Place of Origin: BEIJING
- Brand Name: space
- Model Number: Rubidium
- Weight: 25.000 kg
Frequency: 10MHz
Stability: 5E-10(0℃ to60℃)
Accuracy: 5E-11
Frequency drift: 5E-11/month
Operating temp range: -40℃ to60℃
Supply voltage: 15~35V
Power consumption at turn on: 36W max
Steady state@25℃: 12W min
Output wave form: sine
Output level: 7dBm -2dBm
Load: 50Ω
Harmonic suppression: -30dBc
Non-harmonic suppression: -80dBc
Port: SMA,9 PINS socket
Short term stability:
3E-11/S
1E-11/10S
3E-12/100S
Phase noise:
-80dBc/Hz at 10Hz
-115dBc/Hz at 100Hz
-135dBc/Hz at 1KHz
-140dBc/Hz at 10KHz
-145dBc/Hz at 100KHz
Size: 110x77x38mm
