- Size: 51*41
- Place of Origin: China bejing
- Brand Name: space
- Model Number: OCXO
- Weight: 1.000 kg
Frequency: 5-30MHz
Voltage: 5V, 9V, 12V, 15V
Temp stability: 5x10-10
Operating temperature range: -30-60°C
Output: sine wave 3dBm min
HCMOS/TTL
Voltage control: 0-Vref ±0.5ppm min
Reference voltage: 3.0V, 3.3V, 5.0V
Aging: 0.05ppm/year
Short term stability: 5x10-12/s
Phase noise:
-120dBc at 10Hz, 10MHz
-140dBc at 100Hz
-155dBc at 1kHz
-158dBc at 10kHz
Package size: 51x41x25mm
- Size: 51*41
- Place of Origin: China bejing
- Brand Name: space
- Model Number: OCXO
- Weight: 1.000 kg
Frequency: 5-30MHz
Voltage: 5V, 9V, 12V, 15V
Temp stability: 5x10-10
Operating temperature range: -30-60°C
Output: sine wave 3dBm min
HCMOS/TTL
Voltage control: 0-Vref ±0.5ppm min
Reference voltage: 3.0V, 3.3V, 5.0V
Aging: 0.05ppm/year
Short term stability: 5x10-12/s
Phase noise:
-120dBc at 10Hz, 10MHz
-140dBc at 100Hz
-155dBc at 1kHz
-158dBc at 10kHz
Package size: 51x41x25mm
